Turboshaft Engine PRO XI
Universal Turbine Motor, Industrial Version
Stainless steel casing
5-axis CNC milled superalloy turbine wheel
Brushless Starter/Generator 14 V / 10 Amps
10,6 kW at 20.000 rpm at the output shaft
Clutch bell with spur gear, 20 teeth, Modul 1,5
Length 300 mm, Width 141 mm, 3,6 kg / 8 lbs.
Mounting flange width 60mm
Basic version lubrication from 5% oil component in fuel

The optional dry sump oil system consists of the following components:
Combined Oil Tank/Filter/Air Separator
Two Stage Pump
Heat Exchanger
